All Cable Types
| Type | Tray and VFD Cables |
| Series | TR 600 Plus |
| Gauge/c | 12 AWG/4c |
| Color Code | Black #'d plus ground |
| Jacket | Black special sunlight and oil resistant PVC (RAL 9005) |
| Approvals | UL TC-ER, UL MTW, UL WTTC, UR AWM, CSA CIC, CSA AWM, CE, RoHS |
| Voltage | 600 |
| Temperature Range | -25°C to +105°C |
| View PDF For Complete Technical Specifications |
| Type | Data and Sensor Cables |
| Series | Sensor plus 150 |
| Gauge/c | 26 AWG (7-strand)/6c |
| Color Code | DIN 47100 |
| Shielding | Tinned Braid Shield |
| Jacket | Black PUR 490 with smooth surface (RAL 9005) |
| Approvals | RoHS |
| Voltage | 48 |
| Temperature Range | -50°C to +150°C |
| View PDF For Complete Technical Specifications |
| Type | High Temperature Cables |
| Series | SC 700 HDTR |
| Gauge/c | 14 AWG (≈ 46/30)/16c |
| Color Code | Black #'d plus ground |
| Jacket | Reddish Brown Besilen (RAL 3016) |
| Approvals | UR AWM, CSA AWM, CE, EAC, RoHS |
| Voltage | 600 |
| Temperature Range | -40°C to +200°C; +250°C (short-term use); UL/cUL: up to +200°C |
| View PDF For Complete Technical Specifications |
| Type | Halogen Free Cables (SABIX) |
| Series | SABIX BL 443 C FRNC TT |
| Gauge/c | 22 AWG (≈ 7/30)/2tr |
| Color Code | white, blue, red with printed triple number |
| Shielding | Tinned Braid Shield |
| Jacket | Pigeon Blue SABIX® FRNC (RAL 5014) |
| Approvals | DNV, CE, EAC, RoHS |
| Voltage | 300 |
| Temperature Range | -40°C to +90°C |
| View PDF For Complete Technical Specifications |
| Type | Reeling, Lift and Specialty Cables |
| Series | SAB S 745 Exploration |
| Gauge/c | 10 AWG/1c |
| Color Code | Black #'d plus ground |
| Shielding | Tinned Braid Shield |
| Jacket | Black PUR (RAL 9005) |
| Approvals | UR AWM, cUR AWM, CE, EAC, RoHS |
| Voltage | 500 |
| Temperature Range | -50°C to +90°C |
| View PDF For Complete Technical Specifications |
| Type | ETFE, FEP and FPA Cables |
| Series | TD 833 CF |
| Gauge/c | 26 AWG (7 strand)/7c |
| Color Code | #1- white, #2- brown, #3- green, #4- yellow, #5- gray, #6- pink, #7- blue |
| Shielding | Tinned Braid Shield |
| Jacket | White FEP (RAL 1013) |
| Approvals | UR AWM, cUR AWM, CE, EAC, RoHS |
| Voltage | 600 |
| Temperature Range | -90°C to +180°C |
| View PDF For Complete Technical Specifications |
| Type | Compensating and Extension Cables |
| Series | A 1 L single |
| Gauge/c | 16 AWG/2c |
| Color Code | violet, white |
| Approvals | RoHS |
| Temperature Range | -40°C to +70°C |
| View PDF For Complete Technical Specifications |
| Type | Continuous Flex Cables |
| Series | SABclean S 776 |
| Gauge/c | 16 AWG/5c |
| Color Code | Black numbered conductors with green/yellow ground |
| Jacket | TPE Black (RAL 9005) |
| Approvals | CE, EAC, RoHS |
| Voltage | 500 |
| Temperature Range | -40°C to +80°C |
| View PDF For Complete Technical Specifications |
| Type | Tray and VFD Cables |
| Series | TR 600 Plus |
| Gauge/c | 12 AWG/5c |
| Color Code | Black #'d plus ground |
| Jacket | Black special sunlight and oil resistant PVC (RAL 9005) |
| Approvals | UL TC-ER, UL MTW, UL WTTC, UR AWM, CSA CIC, CSA AWM, CE, RoHS |
| Voltage | 600 |
| Temperature Range | -25°C to +105°C |
| View PDF For Complete Technical Specifications |
| Type | Data and Sensor Cables |
| Series | Sensor plus 150 |
| Gauge/c | 26 AWG (7-strand)/8c |
| Color Code | DIN 47100 |
| Shielding | Tinned Braid Shield |
| Jacket | Black PUR 490 with smooth surface (RAL 9005) |
| Approvals | RoHS |
| Voltage | 48 |
| Temperature Range | -50°C to +150°C |
| View PDF For Complete Technical Specifications |
| Type | High Temperature Cables |
| Series | SC 700 HDTR |
| Gauge/c | 14 AWG (≈ 46/30)/18c |
| Color Code | Black #'d plus ground |
| Jacket | Reddish Brown Besilen (RAL 3016) |
| Approvals | UR AWM, CSA AWM, CE, EAC, RoHS |
| Voltage | 600 |
| Temperature Range | -40°C to +200°C; +250°C (short-term use); UL/cUL: up to +200°C |
| View PDF For Complete Technical Specifications |
| Type | Halogen Free Cables (SABIX) |
| Series | SABIX BL 443 C FRNC TT |
| Gauge/c | 22 AWG (≈ 7/30)/4tr |
| Color Code | white, blue, red with printed triple number |
| Shielding | Tinned Braid Shield |
| Jacket | Pigeon Blue SABIX® FRNC (RAL 5014) |
| Approvals | DNV, CE, EAC, RoHS |
| Voltage | 300 |
| Temperature Range | -40°C to +90°C |
| View PDF For Complete Technical Specifications |
